HSC High-elastic Coupling



The HSC series of highly elastic couplings feature a unique and versatile elastic element design. These can be easily integrated into various coupling configurations to meet multiple application needs. The HSC intermediate elastomer is made of rubber and is compact and easy to install. The element can be attached axially to the flywheel adapter plate or flanged hub and radially to the cylindrical center hub using appropriate bolts. Axial bolt styles include socket head cap bolts with special dry glue or S-bolts similar to dowel pins. Radial bolts are used to attach the element to the cylindrical hub. This unique design is very simple, efficient, and gives the HSC high spring coupling unparalleled performance.



Features:

High elasticity, strong ability to absorb shock and vibration, compact structure, convenient installation, maintenance-free, long service life, radial disassembly and assembly, allowing high rotational speed, and good compensation ability in axial, radial and angular directions. Can be used in combination with shaft series products to form a highly elastic drive shaft.



Applications:

Almost all industrial power transmission systems: such as compressors, pumps, engines, transfer cases, test benches, locomotive drives, wind power, air compressors, marine propulsion, etc.
