Heavy-duty Diaphragm Coupling



Diaphragm coupling is a kind of all-steel coupling without backlash and maintenance. ℃ high temperature.



The RDCE4 and RDCT6/8/10 Heavy Duty Diaphragm Couplings transmit torque entirely through friction and the diaphragm assembly, so there are no stress concentrations, backlash and micro-displacements that can occur when torque is transmitted through the shoulder bolts. It has a near-infinite service life and increases the torsional rigidity of the individual components of the complete coupling.

The high locking force nut and the shaft sleeve are assembled and connected, and the two precision coupling shaft sleeves are installed on the diaphragm by means of friction clamping. The bushing is fixed by means of a DIN 916 fixing nut



Couplings are divided into SD single-diaphragm type and DD double-diaphragm type



Features:

● High rigidity and high torque;

● Zero backlash;

● First choice for medium and low speed applications;

● Simple structure, convenient assembly and disassembly, and adjustable length.



Widely used in:

Various types of pumps and fan units, steel-making equipment, printing machinery, compressors, test benches, cooling towers, generators, paper-making machinery, centrifuges, conveying equipment, mixers, punching machines, etc.
